Name: Perf Trans Panel 1288×1888mm
Brand: Perforated Pool Fencing
SKU: PP-PANEL-TRANS-B
Price: 433.94 AUD
Availability: InStock

The Perf Trans Panel is the taller-format infill panel of the Perf perforated pool fencing system. At 1288mm wide × 1888mm high, this panel is designed for situations requiring taller fence heights — retaining walls, step-down areas, or anywhere a 1.8m–1.9m fence is needed. Fitted into the Trans Frame Kit (sold separately), the finished framed height is 1900mm.

Manufactured from marine-grade aluminium alloy 5052 H32 at 2.5mm thickness, the panel features uniform 9mm precision-punched holes throughout. Unlike the standard 1.2m panel, the Trans Panel is designed specifically for taller applications and uses the Trans Frame Kit rather than the standard Frame Kit.

The textured powder coat finish — available in Matt Black and Monument — is applied by Akzo Nobel, one of the world's leading coatings manufacturers, ensuring long-term colour stability and resistance to the Australian climate including coastal environments.

Unlike glass pool fencing, Perf requires no sealing, polishing, or specialist cleaning. A rinse with fresh water is all that's needed to maintain its appearance, making it an ideal low-maintenance choice for busy households and rental properties alike.

The Trans Panel can be cut down to any smaller size — it is commonly ordered to achieve a finished height of 1.8m. Refer to the fabrication guide in Additional Documentation for cutting and re-fixing instructions.

Common Applications

Pool fencing on retaining walls — where the finished fence must sit higher

Step-down pool areas — transition panels where ground level changes

Boundary and privacy fencing at 1.8–1.9m height

Feature garden walls at taller heights

Any application requiring a taller perforated panel — cut to any smaller size

What's Included

1 × Perf Trans Panel infill (colour as selected)

Trans Frame Kit (PP-TRANSKIT-B/MN), posts and screws are sold separately. Note: the standard Frame Kit does NOT suit this panel — you need the Trans Frame Kit.

Specification	Detail
Panel Dimensions
Panel Width	1288mm
Panel Height	1888mm
Framed Width (with Trans Frame Kit)	Up to 1400mm (shroud install) or 1312mm (U-channel)
Framed Height (with Trans Frame Kit)	1900mm
Panel Thickness	2.5mm
Material & Finish
Material	Marine-grade aluminium alloy 5052 H32
Powder Coat Brand	Akzo Nobel
Finish — Black	Matt black textured powder coat
Finish — Monument	Monument textured powder coat
Perforation Pattern	Full Perf — uniform 9mm holes throughout
Perforation Diameter	9mm
Compliance & Installation
Pool Safety Standard	AS1926.1 compliant (tested)
Installation Methods	Method 1: Horizontal bracket fit \| Method 2: U-channel fit
Frame Profile	38×25mm (Trans Frame Kit sold separately — PP-TRANSKIT-B / PP-TRANSKIT-MN)
Framed Width — Shroud Install	Max 1400mm daylight between posts
Framed Width — U-Channel Install	Max 1312mm daylight between posts
Adjustable	Yes — can be cut down to any smaller size. Commonly used at 1.8m. See fabrication guide.
Product Details
Product Code — Black	PP-PANEL-TRANS-B
Product Code — Monument	PP-PANEL-TRANS-MN
Colours Available	Black \| Monument
Supplied as	Infill panel only (Trans Frame Kit and posts sold separately)
Stock Locations	Brisbane, Gold Coast, Sydney, Newcastle, Melbourne, Adelaide, Perth
Shipping (approx.)
Packed dimensions	200 × 4 × 120 cm
Packed weight	8.0 kg

What exactly is included in this listing?

This listing is for the infill panel only — one panel in your chosen colour (Satin Black or Monument Satin). The frame kit, U-channels, screws, posts and gate hardware are all sold separately. This allows you to order exactly what you need for your specific installation without paying for components you already have.

What framing and hardware do I need to complete a panel?

For a standard 1.2m high framed panel you'll need: 1 × Frame Kit (PP-FRAMEKIT-B or MN) — this includes all 4 frame rails. Plus a pack of SS304 Screws (PP-SCREW-B-50PK or MN) to fix the panel to the frame. For installation you'll also need posts (sold separately — not a Perf product). For U-channel installation, add U-Channels (PP-U-B-2PK) — one pack per panel bay.

What's the difference between Method 1 and Method 2 installation?

Method 1 (Bracket Fit) — horizontal brackets are fixed to the posts, and the framed panel slides into the brackets and is secured. This suits a post daylight of 2150mm for a standard panel. Method 2 (U-Channel Fit) — U-channels are fixed vertically to both posts, and the completed framed panel drops down into the channels. This suits a post daylight of 2012mm. Both methods produce a similar finished appearance. Full step-by-step instructions for both methods are in the Additional Documentation tab.

Can I cut the panel down to fit a non-standard post spacing?

Yes — the panel can be cut to any smaller width or height using a Nibbler tool with a clamped straight-edge guide. Once cut, file any sharp edges. The frame rails are also cut to length using the formulas provided in the fabrication guide. After cutting the panel, you'll need to re-drill pilot holes approximately 50mm from each corner as the original pre-punched border holes may be removed by the cut. The full size adjustment guide is in the Additional Documentation tab.

Is this panel compliant for pool fencing in Queensland (and other states)?

Yes. The panel has been tested to AS1926.1, which is the Australian standard for pool safety barriers. This standard is referenced in pool safety legislation across Queensland, New South Wales, Victoria, South Australia and Western Australia. We always recommend checking with your local council for any state or territory-specific requirements before installation.

What's the difference between the Full Perf panel and the Palm (Deco) panel?

The Full Perf panel has uniform 9mm holes across the entire panel face — clean, minimal and modern. The Palm (Deco) panel has the same specification but features a decorative palm frond pattern created through varied perforation sizing across the panel face. Both are pool compliant and use the same framing. The Palm panel is slightly more expensive. Both are available in Satin Black and Monument Satin.

Can I pick up my order instead of paying for delivery?

Yes — free click and collect is available from warehouses in Brisbane, Gold Coast, Sydney, Newcastle, Melbourne, Adelaide and Perth. After placing your order, allow 1–3 business days for us to process and send you a collection reference and warehouse address. Do not go to the warehouse without your collection reference. Pickup is Monday to Friday, 7:30am–3pm only. The warehouse is not a showroom — goods must be ordered and paid for online before pickup.

How do I know how many panels I need?

Each framed panel covers a 2000mm wide × 1200mm high bay (Method 1 — post daylight 2150mm, Method 2 — post daylight 2012mm). Measure your total fence run length and divide by the appropriate bay width for your installation method to get the number of panels. Don't forget to allow for gates (which replace one panel bay), corners, and any non-standard width bays. Not sure? Send us a sketch of your pool layout and we'll help you calculate a full product list.

How this ships: bulky item — $120 flat metro truck delivery, free click & collect, or freight quote for regional.

Local Delivery

Delivered to your door on purpose-built fencing trucks within metro zones.

Flat fee: $120 inc. GST per delivery regardless of order size.
Timeframe: 1–2 weeks. We'll confirm your delivery date after order is processed.

Zones: Gold Coast, Brisbane, Sunshine Coast, Northern Rivers NSW, Sydney, Newcastle, Central Coast, Wollongong, Melbourne, Geelong, Adelaide, Perth.

Click & Collect — Free

No delivery fee — collect from a warehouse near you.

Locations: Brisbane, Gold Coast, Sydney, Newcastle, Melbourne, Adelaide, Perth.
Hours: Mon–Fri, 7:30am–3pm only.
Processing: 1–3 business days before your collection reference is sent.

Do not go to the warehouse without a collection reference. These are trade warehouses — not retail showrooms.

Regional & Freight

Outside a metro zone? We can arrange palletised freight to a depot near you for collection, or pack your order ready for your own freight carrier.

Packing fee applies — invoiced separately.
Allow up to 2 weeks for packing plus transit time.

Contact us with your postcode and product list for a freight quote before ordering.

Small Items — Courier

Screws, packers and other small accessories can be shipped Australia-wide via express courier.

Calculated at checkout based on weight and postcode.
Timeframe: Usually 2–5 business days.

If ordering a mix of panels and accessories, we can often combine into one order — contact us to discuss.

Christmas & Holiday Periods: During the November–December period and leading into Christmas, processing and delivery timeframes can extend by 1–2 weeks. Plan ahead if you have a deadline.

All prices on this site include GST. No hidden fees at checkout for the product price.
Delivery fee ($120) is charged separately and applies to large/bulky items delivered on our trucks.
Ensure someone is available to receive delivery — panels cannot be left unattended safely.
Any damage must be reported to us within 24 hours of receiving your goods, with photos.
Ensure your vehicle is suitable if collecting — depot staff may refuse to load panels onto unsuitable transport.

Warranty — the honest version

There is no manufacturer warranty on this product. None. Your guarantees under Australian Consumer Law still apply — goods must be of acceptable quality for what they are, and what they are is a budget imported fence, sold as exactly that. Want a 10-year manufacturer warranty on Australian-made fencing? You need Pool Perf®.

All Sales Are Final

Due to the nature of our products — large-format aluminium fencing panels, gates and hardware that are ordered, warehoused and dispatched to order — we do not accept returns or offer refunds for change of mind or incorrect selection.

We strongly encourage you to carefully review your order before confirming purchase. Check your colour selection (Satin Black or Monument Satin), confirm your required quantities, and verify that you have the correct products for your installation method before placing your order.

If you are unsure about what you need, please email us at sales@safestpoolfence.com.au before ordering — we are happy to help you get the right products first time.

Damaged, Defective or Incorrect Items

While we do not accept change of mind returns, we take product quality and order accuracy seriously. If you receive a product that is:

—Damaged — physically damaged during transit or delivery
—Defective — has a manufacturing fault or defect affecting its function
—Incorrect — does not match the product code or colour you ordered

Please contact us within 24 hours of delivery at sales@safestpoolfence.com.au with clear photographs of the issue. We will assess the claim and arrange a suitable resolution, which may include replacement or refund.

Claims made after 24 hours of delivery cannot be accepted — please inspect your order carefully at the time of delivery or collection before leaving the depot or signing off on delivery.

Order Cancellation

Once an order has been placed and payment received, it enters our processing queue immediately. Cancellation may not be possible once the order has been forwarded to the warehouse. If you need to cancel, contact us immediately at sales@safestpoolfence.com.au and we will advise whether cancellation is still possible.

Your Consumer Rights (Australian Consumer Law)

Our policy operates alongside your statutory rights under the Australian Consumer Law (ACL). The ACL provides guarantees that products must be of acceptable quality, fit for purpose, and match their description. These guarantees cannot be excluded by any returns policy. For more information, visit accc.gov.au.

The following resources will help you plan, measure, assemble and install your Perf pool fencing system correctly.

Perf Fabrication & Installation Guide

Complete step-by-step guide covering Method 1 (Bracket Fit) and Method 2 (U-Channel Fit), panel size adjustment, and gate hardware options.

→

Delivery & Pickup Information

Full details on delivery zones, click & collect locations, processing times, freight options and what to expect when collecting from a warehouse.

→

Pool Safety Compliance — AS1926.1

All Perf panels have been independently tested to AS1926.1. Test reports and compliance documentation available on request — email sales@safestpoolfence.com.au.

✉

Not Sure What You Need?

Send us a sketch or photo of your pool area with measurements and we'll prepare a complete product list and quote — no obligation. Email sales@safestpoolfence.com.au.

✉
